Introducing our advanced UHMWPE UD Fabric Prepreg Machine, designed for manufacturing high-quality UD fabric using PE fiber or aramid fiber. As a leading factory based in China, we specialize in providing innovative solutions for composite materials. This state-of-the-art machine comprises several essential components: Unwinding, Spreading, Impregnating, Laminating with Carrier, Heating Drying, Accumulating, and a Rewinder with Double Roll Automatic Changing. Our product is optimized for efficiency, ensuring that suppliers and manufacturers can achieve superior results in their fabric production processes. Choose us for reliable, high-performance equipment tailored to your needs in the composites industry.
    MORE DETAILS AND CUSTOMIZATION

    Prepreg Machine Description

    Kuntai Group
    Place the fiber on the rack of prepreg machine, roll back to the cluster device and arrange in parallel. Then parallel them after the cluster pass through the finishing device to form the parallel and closely packed filament bundles. After the spread of the fibre, add tension to ensure the smoothness of the fibre. After impregnating the fiber with the adhesive device, combining with the membrane after the adhesive device. After the heat roller evaporation resin curing, forming the fabric.

    Applicable Adhesives

    Kuntai Group
    Resin, hot melt film, etc.

    Accessories Option

    Kuntai Group
    Unwinder

    Unwinder

    Spray Device

    Spray Device

    Scatter Device

    Scatter Device

    Pressing Device

    Pressing Device

    Rewinder Device

    Rewinder Device

    Double Stand Winder

    Double Stand Winder

    Accumulator

    Accumulator

    Coating System

    Coating System

    Center Unwinder

    Center Unwinder

    Surface Rewinder

    Surface Rewinder

    Prepreg Machine Features

    Kuntai Group
    Fibre Unwinding Spreading Impregnation Line
    Automatic Impregnation Lamination Line
    Prepreg Heating Drying Rewinder Line
    Composite Impregnation System
    UD Fabric Impregnation Machine
    1. The non-weft fabric production line adopts stable mechanical operation rollers and special-shaped devices to spread the fibre evenly, impregnate with resin glue and lamination with the carrier PE film, dry and solidify, and then go through the 0/90º orthogonal lamination in the back. The product has excellent properties such as low density, abrasion resistance, impact resistance, and strong cutting resistance.
    2. The equipment uses resin adhesives to produce non-weft fabrics.
    3. Adopt HMI+PLC control system, easy operation, high production efficiency, and reduce the tedious operation.
    4. The mirror surface processing rollers are used for fibre pulling and fibre laying to ensure that the damage to the fiber performance is reduced to the greatest extent during the operation.
    5. The machine adopts gear transmission, which has strong torque transmission and stability.

    Prepreg Machine Technical Parameters (Customizable)

    Kuntai Group
    Machine roller width 1800mm
    Max material width 1650mm
    Gluing method Dipping glue
    Spreading method Mechanical multi-roller+special shaped
    Control mode HMI+PLC
    Drive control Variable frequency drive
    Heat source mode Oil heater
    Temperature control method Module
    Roller surface treatment Mirror surface of the friction roller of the whole machine
    Dynamic balance Mirror roller heating roller of the whole machine
    Total power 90kw
    Lamination speed 3-11m/min
    PLC Brand Mitsubishi
    Main Motor Brand Siemens
    Inverter Brand Yaskawa
    Electrical Parts Brand Schneider/Omron
    Temperature Control Brand Fuji

    Prepreg Machine Application

    Kuntai Group
    Application and Usage of Prepregs:
    Space and Air craft (aerospace) structure and parts
    Blades for wind turbines
    Automotive parts and components
    Recreational sports equipment
    Industrial structure and parts
    Military
    Civil and Building Reinforcement
    Application product
    Application example 2
    Application example 3
    Application example 4
    Application example 5
    Application example 6

    Packaging And Shipping

    Kuntai Group
    Prepreg Machine Inner Package: Protective Film, etc.
    Prepreg Machine Outside Package: Export Container
    ◆ Machines well packed with protective film and loaded with export container;
    ◆ One-Year-Period spare parts;
    ◆ Tool kit
    Packaging step 1
    Packaging step 2
    Packaging step 3
    Packaging step 4
    Packaging step 5
    Packaging step 6
    Packaging step 7
    Packaging step 8

    Above infos are only symbolic. No responsibility is accepted for the accuracy of given information. All machines details will need to be discussed and confirmed before production as per specific application requirements.

    Company Jiangsu Kuntai Machinery Co., Ltd
    Phone / Whatsapp 008615862082187
    Address Zhengang Industrial Park, Yancheng City, Jiangsu Province, China
    Contact Us

    We are a leading manufacturer of coating lamination machines, cutting machines and other materials finishing machines, pls kindly let us know your details requirements.

    Frequently Asked Questions (FAQ)

    Kuntai Group

    What working widths are supported by the prepreg machine?

    The standard machine roller width is 1800mm with a maximum material width of 1650mm. However, machine dimensions and roller configurations can be fully customized according to your specific production demands.

    Which adhesive media can be processed on this line?

    The system supports dipping resin adhesives, hot melt film, and various composite impregnating agents to form high-performance non-weft and prepreg fabrics.

    How does the machine avoid damaging sensitive fibers during operation?

    The line incorporates high-precision mirror surface processing rollers for fiber pulling and laying, alongside smooth tension control, ensuring zero or minimal mechanical abrasion on delicate carbon or glass fiber filaments.

    What automation and control system brands are equipped?

    The machine utilizes Mitsubishi PLC with an intuitive HMI interface, Siemens main drive motors, Yaskawa variable frequency inverters, Fuji temperature modules, and Schneider/Omron electrical components.

    What standard packaging and accessories are provided upon delivery?

    All equipment is securely covered with protective film for sea-freight containers. Each delivery includes standard toolkit sets and a dedicated one-year supply of critical maintenance spare parts.
